What size are e track bolts

They have a diameter of #14 and the screws are 1″ long. Use a 3/8″ diameter drive to fasten screws. The screws are zinc-plated, improving corrosion- and rust-resistance. They are also available with 1.5″ and 2″ long bolts.

What size bolt holes are in E track?

Expert Reply: The mounting holes on the E-Track such as # E19148 are 1/4 inch in diameter. The type and length fastener you use will depend on the surface material and thickness you are attaching it to. For example if your surface was ACQ treated wood you could use # TFX250ACQ which is 2-1/2 inches long.

Is all e track the same size?

E Track rails are available in a variety of different lengths in both Vertical E Track and Horizontal E Track varieties. Some of the most common lengths of E Track rails are 2′, 5′, 8′, and 10′ being the longest piece of E Track rails.

Can you cut E track?

Expert Reply: The Erickson Horizontal E-Track # E19148 can be cut to length for your application. We suggest using a metal saw or cutting wheel and grinder to cut the tracks to the needed length.

How wide is E track?

The E-Track has slots that have a length of 2.45-inches and a width of . 58 inches. See attached diagram.

Is E track stronger than L track?

When deciding between the two systems consider your purpose and what you’re trying to secure. L-Track is light, sleek and can be coordinated with the paint on your truck or trailer. E Track is stronger, heavier and much more industrial. Both will work inside of a trailer — just consider what you were trying to do.

What height do you mount an e track in an enclosed trailer?

There isn’t a specific height from the trailer floor recommended to mount the E-Track. My gut feeling is that if 3 feet is too low and 4 feet is too high then 3-1/2 feet might be perfect.

What is the difference between vertical and horizontal e track?

Vertical e-track has slots that run parallel with the track, whereas horizontal e-track has slots that run perpendicular. … Horizontal e-track gives you more tie-down points per foot, however, vertical e-track mounted on the wall lets you attach items perpendicular to the floor of the trailer.

How strong is E track?

The E-Tracks provide a 6000-pound capacity (except for the 2-foot E-Track), which means the system can handle extra-heavy loads.

Who manufactures E track?

Manufacturer‎EricksonBrand‎EricksonModel‎Erickson ManufacturingItem Weight‎2.6 poundsProduct Dimensions‎24 x 5.2 x 0.4 inches

Article first time published on

Where do you put E tracks on a trailer?

Your trailer’s cargo is only as secure as the weakest part of the tie-down assembly. Due to this, it’s best to install an e-track into the wall studs and floor studs of your trailer or van. It is also essential to choose the best self-tapping screws for your trailer.

What screws do you use for e track?

Bolts will give you the strongest hold, but require access to the underside of the mounting surface. If you choose screws, you’ll need #12 or #14 screws. If you’re using bolts, use ¼” bolts. Screws should be long enough to get a grip in the stud, but not too long to puncture the outer skin of the trailer.

Will E track hold a car?

Expert Reply: Yes, the Erickson Horizontal E-Track part # E19148 will be plenty strong enough to secure your two rock crawler buggies. The tracks are each rated at 6,000 lbs max break strength and 2,000 working load limit.

What is vertical E track?

Vertical e-track has rectangular slots that run parallel with the e-track rail. Vertical e-track is commonly used in van trailers and is an excellent way to provide a support system for shoring beams (or “decking beams”), which creates a second level for cargo.

What is E track?

What is E Track? E-Track is essentially long rails of high-strength 12-gauge steel with multiple anchor points that support various tie-down equipment. People commonly install E-track inside enclosed trailers, cargo vans, or dry van semi trailers.

Can you weld Etrack?

We install E track in steel bodies. … It can be welded, but specific precautions should be used when doing so as this is a zinc-coated steel and welding produces dangerous fumes. It should always be done in a ventilated area.

Can you overlap E track?

The E-track pieces are not designed to be mounted properly while overlapped with one another. I recommend cutting one of the tracks down with a saw or cutting wheel if the piece is too long to mount onto the wall stud.

How thick are cargo trailer walls?

Normally ranging in thickness from . 024 – . 050, aluminum is the most common form of exterior.

How much weight can an L-track Hold?

L-Track (Logistic Track, also sometimes known as “airline track”) is the standard securement for air cargo. L-track single-stud fittings have a working load limit of 1333 pounds (breaking strength of 4000 pounds), and double-stud fittings have a working load limit of 2833 pounds (breaking strength of 8500 pounds).

What is the difference between S track and L-track?

The only difference between an S-track roller and an L-track roller is that the S-track roller is extended from the neck to the lower back, whereas the L-track roller extends from the neck to the glutes or hamstrings depending on the model.

Why is it called L-track?

The “L” gained its name because large parts of the system run on elevated track.

How wide is vertical E-track?

The vertical E-track part # E19146 is currently available and will come in 4 foot pieces and can be mounted on the floor or wall. The overall width is 3-1/2 inches. The slots each have a length of 2.41-inches and a width of . 55 inches.
