What is PrimeTime used for

PrimeTime is a stand-alone static timing analysis tool, which is based on the universally adopted EDA tool language, Tcl. A brief section is included on the Tcl language in context of PrimeTime, to facilitate the designer in writing PrimeTime scripts and building upon them to produce complex scripts.

What is DMSA in PrimeTime?

Primetime provides an efficient way to analyze timing at different corners and different operating modes. MMMC (multi-mode multi corner) refers to performing timing analysis at various modes and corner. Distributed Multi-Scenario Analysis (DMSA) refers to timing analysis at different scenarios in a distributed manner.

What is static timing analysis in VLSI?

Static timing analysis is a method of validating the timing performance of a design by checking all possible paths for timing violations under worst-case conditions. It considers the worst possible delay through each logic element, but not the logical operation of the circuit.

What is DMSA in VLSI?

Distributed Multi-Scenario Analysis (DMSA) allows multiple scenarios to be run concurrently, which reduces wall clock time and produces a single comprehensive timing report.

What is another word for prime time?

heydayprimeacmeheightfloruitflushculminationfloweringtimeday

What is Prime Time Synopsys?

PrimeTime is a Static Timing Analysis (STA) tool from Synopsys. This is a simple description to use PrimeTime for VLSI class project. In Project #6, you will learn to find critical path using PrimeTime from your synthesized Verilog code. Go to your PrimeTime working directory first.

What is fusion compiler?

Overview. Fusion Compiler™ is the next generation RTL-to-GDSII implementation system architected to address the complexities of advanced process node design and deliver up to 20% improved quality-of-results (QoR) while reducing time-to-results (TTR) by 2X.

What is mode in VLSI?

A mode is defined by a set of clocks, supply voltages, timing constraints, and libraries. It can also have annotation data, such as SDF or parasitics files. Many chip have multiple modes such as functional modes, test mode, sleep mode, and etc.

What is scenario in VLSI?

In ICCompiler, we create `scenarios` to specify the different corners and modes the design should operate on. In a `scenario`, you can have constraints which determine the mode of operation, and different libraries(or opertaing conditions) which determine the corners.

What is early and late in VLSI?

For Setup analysis, it uses the late value for each startpoint and the early value for each endpoint. For hold analysis, it uses the early value for each startpoint and the late value for each endpoint.
