What is a Wellpoint system

Wellpoint systems are used to lower groundwater levels to provide stable working conditions in excavations. … A wellpoint system consists of a series of closely spaced small diameter shallow wells. The wellpoints are connected to a common header pipe and are pumped with a high efficiency vacuum dewatering pump.

What is the difference between a Wellpoint and a borehole?

WHAT IS THE DIFFERENCE BETWEEN A WELLPOINT AND A BOREHOLE? A wellpoint is a polyethylene pipe with a filtered end installed into a porous soil structure. … A borehole is a shaft drilled to depths exceeding 20 metres with a large diameter casing allowing for the installation of a submersible pump to distribute the water.

What is a well point in construction?

Well Point is a well of small diameter that is used for dewatering. Parts consisting in a Well Point are a shallow shaft, a dewatering pump to draw water, a riser pipe that connects the Well Point to the surface, and a small well that fills up. The diameter of a riser pipe is around 38 to 50 mm.

How does a Wellpoint pump work?

The wellpoint pump creates a partial vacuum in the header main, which draws up the water so that it can be discharged at a designated point. Typically, wellpoints are installed around the perimeter of an excavation, or parallel to a pipeline trench, by either jetting, auguring or traditional drilling techniques.

Why dewatering is done?

Dewatering is a term to describe the removal of groundwater or surface water from for example a construction site. In construction the water is pumped from wells or sumps to temporarily lower the groundwater levels, to allow excavation in dry and stable conditions below natural groundwater level.

How much does a Wellpoint cost?

How much do they cost? Prices do vary from company to company but De Wets Wellpoints & Boreholes says that their standard price for supply and installation of a wellpoint is R6, 850 including VAT.

Is Wellpoint water safe to drink?

Groundwater outside of cities is often safe to drink, but it is wise to assume that all borehole and wellpoint water in Cape Town should be treated before it would be suitable as drinking water.

What is the best Wellpoint pump?

The PT positive displacement pump is by far the best choice to guarantee a dry pit during site dewatering. These pumps are usually diesel driven and feature a sound attenuated canopy. The pump can also be supplied with an electric drive or in open frame.

Can a borehole dry up?

Boreholes can also dry up! Hydro-geologists have cautioned that groundwater has an important ecological function and for that reason its use should be meticulously monitored to ensure that the water source is not exploited.

How do you dewater soil?

Normally the dewatering process is done by pumping or evaporation. It is usually done before excavation for footings and will help to lower the water table that might cause problems during excavations. Dewatering can also refer to the process of removing water from the soil by wet classification.

Article first time published on

What is a well point for a pool?

A wellpoint system is a point that provides a point of least resistance. Since water always seeks the point of least resistance, these allow the water to follow this path and be removed and taken away from the pool. “We will typically try and determine the point around the pool where the water appears most present.”

What are the different types of well point system?

There are two types of well point system, namely single stage well point system and multi-stage well point system. These systems are briefly described in the followings. Single Stage Well Point system – A well point consists of a pipe about 1 m long and 50 mm in diameter.

Why are well points used?

A wellpoint, also known as a drive point, is a small diameter well used for dewatering. It consists of a shallow shaft, a dewatering pump to draw water, a riser pipe which connects the wellpoint to the surface, and a small ‘well’ that fills up.

What are multi stage well points?

Multi stage or multi-level well point is mostly preparable where excavation depth is more than 15 feet and there is a chance of slope failure to excavation. Firstly, well point is operated to lower the water table up 15 feet depth from the level of installation.

How do you drill a Wellpoint?

1. Start a pilot hole. Using a post hole digger or shovel, dig a hole two feet deep. …
2. Install your well point. Well points are generally made of steel or any other hard metal so that they can withstand being driven deep into the ground. …
3. Begin driving the well point. …
4. Add each extension of pipe.

How deep can a Sandpoint well be?

Atmospheric pressure of about 14.7 pounds per square inch allows a shallow-well pump to pull water up from a maximum depth of only about 20 feet (Figure 2).

Is a sand point well good?

Sand Point Well Benefits A sand point well offers many potential benefits over a drilled well. … Since the equipment used to install a sand point well is smaller, the process is also far less invasive than drilling a well. It can also generally be done more quickly and with less of a mess.

What does dewatering mean in construction?

Dewatering is defined as the intentional removal of groundwater or surface water from a location. Natural evaporation aside, a dewatering process typically involves removing surface or groundwater from the construction site by pumping.

What 3 things can drainage and dewatering requirements include?

It includes: planning and preparing; positioning sedimentation control; remove surface water; constructing sump and wells; removing water from sumps or wells, trenches and pits; and cleaning up. Refer to Unit Descriptor.

How does a dewatering system work?

The dewatering process in construction sites involves the removal of groundwater or surface water from the workplace. The process is usually carried out by pumping or through evaporation before excavating the ground for footing. It also helps to lower the water table for rapid excavation.

What will happen if you drink borehole water?

The effects of poor groundwater quality For example, a high magnesium concentration may result in an upset stomach for a few days. However, exposure to high levels of nitrates will reduce the amount of oxygen in the blood and could cause a condition known as methemoglobinemia.

Can one drink borehole water?

In short, yes, borehole water is usually safe to drink. However, The Private Water Supplies Regulations has said that you must have your private water supply checked to ensure it is consistent with drinking water standards.

How can we keep water clean in South Africa?

1. Set Up Rain Catchment Tanks. In areas that receive adequate rainwater, a rain catchment system can be an economical solution to water scarcity. …
2. Protect Natural Springs. …
3. Install Sand Dams. …
4. Rehabilitate Old Wells. …
5. Build New Wells.

How much does it cost to drill a borehole in Cape Town?

The Aquify Cape Town Borehole company said the cost of drilling a borehole can range between R35 000 to R100 000, depending on the area and soil conditions.

How much does it cost to drill a borehole in South Africa?

The Borehole Water Association of South Africa says the average drill cost is around 600 a meter, but this can be as much as R900 per meter depending on the company. “Yield testing will set you back somewhere between R2,000 and R5, 000 while the equipment might cost between R20, 000 and R40, 000.

How much does it cost to drill a borehole?

The average drilling cost is around R 600 a metre, according to the Borehole Water Association of Southern Africa (BWA). Once drilling is done and groundwater has been found, there’s another outlay for installing a pump – about R25 000 to R30 000 – and then about R 12 000 for the laboratory water tests.

What causes borehole failure?

The common causes of borehole failure in the crystalline rocks of SW Nigeria are seasonal variations in water level, improper casing of the overburden, damage to pumps and other system failures such as blocked pipelines and malfunctioning tanks.

How deep does a borehole need to be?

How Deep Does A Borehole Need to Be? Drilling a borehole for household use will usually range from about 100 feet to 500 feet deep, but when drilling a new borehole for your home or business, the depth of the well depends on the geology and underground water levels of the area.

What well pump do I need?

In most cases, if the well is less than 25 feet deep, a centrifugal or shallow-well jet pump is suitable. If the well is between 25-110 feet, a deep-well jet pump is usually ideal. For deeper wells, a submersible pump may be the best choice.

Which type of pump is used to dewater from deep well?

These can be dewatered by pumping from deep wells by using a turbine or a submersible pump. The main significance of deep wells as a means of dewatering is that they can be installed all around the periphery of the excavation.

How do you dewater a basement?

The best dewatering (or basement waterproofing) systems include an interior baseboard drainage system around the perimeter of the basement. This drainage system will direct the water to a sump pump, which then discharges the water from the home and downhill away from the house, effectively protecting the home.
