What does SAE Grade 5 mean

SAE GradeSize Range (in)Minimum Tensile Strength (103 psi)21/4 – 3/4 7/8 – 1 1/274 6051/4 – 1 1 1/8 – 1 1/2120 1055.21/4 – 112071/4 – 1 1/2133

What is SAE Grade 5?

SAE GradeSize Range (in)Minimum Tensile Strength (103 psi)21/4 – 3/4 7/8 – 1 1/274 6051/4 – 1 1 1/8 – 1 1/2120 1055.21/4 – 112071/4 – 1 1/2133

Is Grade 5 a strong bolt?

Grade 5 bolts are hardened to increase strength and are the most common bolts found in automotive applications.

What does grade 5 Mean on a bolt?

Grade 5 Bolts and fasteners are made of medium strength carbon steel and are specified under the Society of Automotive Engineers (SAE). If your application calls for heavier materials, you may need Grade 8 Bolts because they are the hardest and are often used in heavy manufacturing applications.

How would you identify a Grade 5 SAE bolt?

Grade 5 bolts are case hardened, meaning the bolt has been heated enough to hardened the outside of the bolt but not enough to harden the inside portion. Grade 5 bolts are identified by 3 evenly spaced radial lines on the head.

Is grade C the same as Grade 5?

Grade/ClassStrengthGrade C NutsStrength exceeds Grade 5. Use with heat-treated medium-strength steel fasteners like ASTM A325 structural bolts.

Will Grade 5 bolts rust?

Many other grades exist but are used far less often. Grade 2, 5, and 8 are usually plated with a slightly blue-ish or yellow zinc coating, or are galvanized, to resist corrosion.

Are Grade 5 bolts stainless?

Stainless Steel Grades & Strength Stainless commonly comes in grades 18.8 (304) or T316. Stainless steel bolts are rated for corrosion resistance. … A stainless steel bolt has the same PSI rating as a grade 5 bolt (125,000 PSI). A grade 8 bolt has a stronger rating with a PSI of 150,000.

Is Grade 5 the same as A325?

ASTM A325 bolts are very similar to SAE Grade 5 bolts in regards to their chemical and mechanical properties. The main difference between the two can be found primarily in the applications that they are specified for as well as their configuration.

What is the strongest bolt grade?

Commercial-grade 8 bolts are the strongest option available. They’re made from medium carbon alloy steel and have markings that include six raised dashes. The psi of the bolt is 150,000, meaning that it can withstand great deals of pressure because of the way it was quenched and tempered.

Article first time published on

What is the total strength of Grade 5?

GradeNominal Size, inchesTensile Strength, min, psi21/4 thru 3/474,000Over 3/4 thru 1-1/260,00051/4 thru 1120,000Over 1 thru 1-1/2105,000

What is the shear strength of a Grade 5 bolt?

For example, an SAE grade 5 hex cap screw has a specified minimum tensile strength of 120,000 psi. Therefore, for design purposes, its shear strength could be reasonably assumed to be 70,000 psi.”

What is the difference between Grade 2 and Grade 5 bolts?

Grade 2 is a standard hardware grade steel. This is the most common grade of steel fastener and is the least expensive. Except a possible manufacturer’s mark,Grade 2 bolts have no head marking. Grade 5 bolts are hardened to increase strength and are the most common bolts found in automotive applications.

What material is a Grade 5 bolt made of?

Grade 5. Grade 5 alloy steel is a medium carbon zinc plated alloy steel that is heat treated to increase hardness. Grade 5 bolts have three (3) evenly spaced hash marks on the head markings (manufacturers mark may also be included).

How strong is a Grade A bolt?

Bolt Grade Markings & Strength Chart – Metric Steel BoltsHead MarkingGrade/SpecificationTensile Strength min (MPa)Class 10.91040 (150,000 psi)Class 12.91220 (176,000 psi)Usually stamped A-2 or A-4A2 & A4 Stainless500 Min 700 Typical

How can you tell the difference between Grade 8 and Grade 5 bolts?

First, you need to be able to identify bolts by the different grades when you go to the local hardware store. Grade 5 bolts have 3 marks or lines on the head that are in the shape of a “Y”. Grade 8 bolts have 6 marks on the head.

Do zinc coated screws rust?

Galvanised screws and nails are zinc coated nails that have undergone a galvanisation process. This process means the nails have a protective barrier which makes them resistant to rust and corrosion.

Are stainless steel bolts stronger than zinc plated?

Zinc is cheaper than chromium, and therefore, in general, zinc alloys are relatively less expensive than compared to stainless steel. Though more expensive, stainless steel is a strong, tough material noted for its corrosion resistance. Though some Zinc alloys can be very strong, overall stainless steel is stronger.

Are galvanized bolts rust proof?

Galvanized steel is coated with a thin layer of zinc. The zinc coating protects the steel beneath it from rust. It’s used to make nuts, bolts, screws, and nails resistant to degradation when they are exposed to the weather. Galvanized steel stands up to water well — as long as it’s not salt water.

Is Grade A Grade 5?

Fifth grade (called Grade 5 in some regions) is a year of education in the United States and many other nations. The fifth grade is the fifth school year after kindergarten. Students are usually 10 – 11 years old. … This begins as early as the third grade in some schools.

What is SAE J429?

SAE J429 is a Society of Automotive Engineers specification for fasteners. SAE J429 covers fasteners sizes up to 1-1/2″ inclusive. Used in automotive and related industries, these fasteners can be found in small quantities in automotive and home improvement stores.

What is a Grade F nut?

F. This nut grade is for use with grade 5 bolts and usually denotes hex flange nuts.

Are all Grade 5 bolts the same?

Grade 5 bolts range from ¼” to 1 and ½” in diameter. A different classification is necessary for bolts larger than 1 and ½”. When completed, a manufacture Grade 5 bolt is a finished hex bolt with nuts that also feature a pattern that is finished hex.

What is the hardest bolt?

Grade 9 structural bolts, also known as grade 9 hex cap screws, are one the strongest structural bolts that can be used today. While the typical grade 8 bolt has a tensile strength of 150,000 PSI, a grade 9 bolt has a tensile strength of 180,000PSI.

Can you weld Grade 5 bolts?

If you take a heat treated bolt, such as an SAE Grade 5 or 8, or metric 8.8 or 10.9, and weld on it, you’ve changed the heat treatment, so you have no idea of the new strength. … Therefore, the recommendation is to never weld on a heat-treated bolt.

Is Grade 5 harder than stainless?

The hardest standard stainless steel is X30CrMoVN15-1 and can be quenched and tempered. It can reach more than 2000 N/mm². It is stronger than titanium grade 5. However it is a bearings steel and is not used in standard bolts.

Are yellow zinc screws rust proof?

Yellow-zinc coated steel Some fasteners with this electro-plated coating are labeled as being corrosion resistant, but they are not appropriate for exterior applications.

What is the strongest stainless steel bolt?

BUMAX® Ultra has proven itself as the world’s strongest bolt – in various highly-demanding critical fastener applications around the world where standard fasteners are simply inadequate.

What does 8.8 mean on the head of a bolt?

So, in English, a PC 8.8 bolt is a bolt with a nominal tensile strength of 800 MPa and a nominal yield strength that is 80% of the bolt’s nominal tensile strength, or 640 MPa.

Are titanium bolts stronger than steel?

The strength and low weight of Titanium make it exceptionally unique, and some grades of Titanium can be anywhere from two to four times stronger than some grades of Stainless Steel.

Are stainless steel bolts stronger than high tensile?

Stainless steel fasteners available on the Australian market in the main are equal to or higher in tensile strength than the carbon and low alloy steel fasteners commercially used, and are higher strength than most other corrosion resistant fasteners.
