How far can you span a TGI

According to TJI’s span table, switching to deeper 11-7/8 inch joists (a nominal 2×12), even when spaced at 19.2 inches on-center, enable you to go as long as 17 feet, 4 inches and still achieve L/480.

How far can a TJI floor joist span?

According to TJI’s span table, switching to deeper 11-7/8 inch joists (a nominal 2×12), even when spaced at 19.2 inches on-center, enable you to go as long as 17 feet, 4 inches and still achieve L/480.

What joist can span 20 feet?

Maximum Span (ft – in)Nominal Size (inches)Joist Spacing Center to Center (inches)Lumber Grade2 x 82412′ – 4″2 x 101220′ – 3″1618′ – 5″

How far can TJI joists cantilever?

TJI® joists are permitted to be cantilevered up to 1/3 the adjacent span if not supporting concentrated loads on the cantilever. Cantilevers exceeding 4 feet may require special consideration.

How far can a web joist span?

Joists are most commonly used at 600mm centres, but can span further at 400mm centres – why not use our joist span table to help you calculate the possibilities?

What are TJI floor joists?

Trus Joist® TJI® joists are a key part of making a high-performance floor. TJI joists are lightweight and come in long lengths, which makes them faster and easier to install than traditional framing, and saves you both time and money. …

What does TJI joist stand for?

TJI. Trus Joist I-Joist (engineered floor and roof joist; trademark of Trus Joist, a Weyerhaeuser Business)

How wide is a TJI joist?

This guide features TJI® joists in the following sizes: Flange Widths: 2½” and 3½” Depths: 9½”, 117⁄8″, 14″, 16″, 18″, and 20″ Weyerhaeuser offers a series of joists made in Canada: Trus Joist® TJI® s31, s33 and s47 joists.

How far can a 11 7 8 tji span?

TJICHORD DEPTH16″ O.C. MAX SPANTJI-2309-1/2″16′ 2″TJI-11011-7/817′ 10″TJI-21011-7/8″18′ 8″TJI-23011-7/8″19′ 2″

Can a 2X10 span 20 feet?

2×10 floor joists can span up to 20′. … If you have Spruce-pine-fir lumber, then your span changes to 13′ 7” for 16” joist spacing. Redwood can support a 2×10 joist up to 13′ – one entire foot less than Southern yellow pine.

Article first time published on

What size beam do I need to span 25 feet?

For 25 foot span, size of simply supported beam for 2-3 storey residential building, using thumb rule, is about 15″×18″ in which beam width is 12″ and beam depth is 15″, if width will be kept 12″, depth should increased, then beam size 12″×24″ can be used, providing with 4nos of 16mm bar at top, 4nos of 20mm bar at …

What size beam do I need for a 20 foot span?

Wood beam size for a 20 foot span:- as per general thumb rule, for a 20 foot span, size of wood beam or lumber joist should be 2×14 which placed at 16″ apart from centre used for residential building or projects or construction in which depth of section of beam is 350mm (14″) and width of beam is 50 mm or 2″.

How far can I span a 2X10 floor joist?

Douglas fir 2-by-10 joists graded as “Structural Select” allows joist spans up to 21 feet for a live load of 30 pounds per square foot when spaced 12 inches apart, 19 feet 1 inch for 16 inch spacing and 16 feet 8 inches for 24 inch spacing.

How far can a 2X8 joist span?

Depending on various factors, the maximum span for a 2×8 floor joist is 16′ 6”. The maximum span for roof rafters is 23′ 9”. For headers, the maximum span is 11′ 2”.

How far can you span a triple 2X10 beam?

Joist SpansSouthern Pine3-2X108′-9″3-2X1210′-6″Douglas Fir-Larch, Hem-Fir, Spruce-Pine-Fir, Redwood, Cedars, Ponderosa Pine, Red Pine3X6 OR 2-2X63′-7″3X8 OR 2-2X84′-7″

Can TJI joists get wet?

Like all wood materials, I-joists are susceptible to moisture. Avoid unnecessary moisture exposure of all wood components by enclosing the frame against adverse weather as soon as feasible.

Who makes TJI joist?

Weyerhaeuser TJI® Joist Floor Framing includes a series of joists made in Canada: Weyerhaeuser Trus Joist® TJI® s31, s33 and s47 joists.

What is the longest span for floor joists?

A floor joist can span nearly 26′ in the most extreme cases. A select douglas fir 2×12 supporting a 30 psf live load and 10 psf dead load, spaced at 12” will have the greatest span length.

What is a tji 210?

Sold by lineal foot. Trus Joist® TJI® joists are lightweight, easy to work with, and deliver unmatched dimensional stability and performance. They are engineered to resist the bowing, twisting, and shrinking that can lead to squeaky or “soft” floors. 2-1/16 inches x 9-1/2 inches. Engineered for strength and consistency.

How far can you span 12 I joist?

You can go up to 17 feet, 9 inches if you use 9-12 inch-deep joists that are 12 inches on-center.

How far can 2x12 span?

A 2×12 with an E of 800,000 psi and Fb of 790 psi also works, since it can span 15 feet and 10 inches. Given a design span of 15 feet 1 inch and a 16 inch joist spacing, first determine which size lumber will work.

Do TJI joists require bridging?

Trus Joist® TJI® joists are made with no observable twist and have minimal material variation between joists within any joist series/depth. … Our code report (ICC ESR-1153) specifically states that bridging is not required for floor and roof TJI joist applications.

How far apart should blocking be?

Blocking must be equally spaced in rows, maximum of 4 to 6 feet apart. WHY IS BLOCKING NEEDED? Solid wood blocking will help reduce up or down movement and/or twisting of joists.

Can tji be used for rafters?

Wood I-joists are used as a framing material primarily in floors, but may also be used as roof rafters where long length and high load capacity are required. They are used as an alternative to sawn lumber.

What is a tji 230?

Sold by lineal foot. Trus Joist® TJI® joists are lightweight, easy to work with, and deliver unmatched dimensional stability and performance. They are engineered to resist the bowing, twisting, and shrinking that can lead to squeaky or “soft” floors. 2-5/16 inches x 9-1/2 inches. Engineered for strength and consistency.

What size beam do I need for a 16 ft span?

LVL beam size for a 16 foot span:- as per general thumb rule, for a 16 foot span, size of LVL beam or GLULAM should be 7-8 inches deep and 3 inches wide, thus you need something like a 7-8″ GLULAM or LVL to span upto 16 feet used for residential building or projects.

How much weight can a tji hold?

Depth TJI® 40 PSF Live Load / 10 PSF Dead Load 40 PSF Live Load / 20 PSF Dead Load 12″ o.c. 16″ o.c. 19.2″ o.c. 24″ o.c. 12″ o.c. 16″ o.c. 19.2″ o.c. 24″ o.c.

What size beam do I need to span 24 feet?

For 24 foot span, size of simply supported beam for 2-3 storey residential building, using thumb rule, is about 15″×18″ in which beam width is 12″ and beam depth is 15″, if width will be kept 12″, depth should increased, then beam size 12″×24″ can be used, providing with 4nos of 16mm bar at top, 4nos of 20mm bar at …

How far can a doubled up 2x10 span?

A double ply beam can span in feet if there is no overhang beyond it. A double 2×12 beam can span 12 feet, a double 2×10 can span 10 feet, and so on.

Can a 2x8 span 20 feet?

The distance a 2×8 can span depends on species, grade, purpose, location, loads, and several other factors. Joist spans range from 7′-1” to 16′-6 when all factors are considered. Most select structural (SS) and #1 grade lumber will span 12-feet or more, with SPF falling shy of that span.

What size beam do I need for a 15 foot span?

Wood beam size for a 15 foot span:- as per general thumb rule, for a 15 foot span, size of wood beam or lumber joist should be 2×10 which placed at 16″ apart from centre used for residential building or projects or construction in which depth of section of beam is 250mm (10″) and width of beam is 50 mm or 2″.
