How far can Trex overhang

Trex is a popular composite material with a maximum overhang of 102mm or around 4 inches. Between one and two inches of deck board overhang is ideal when you attach an outer fascia board, or at least 1 ¾” to 2 ¾” of overhang before installing the fascia.

Can composite decking overhang?

Just like traditional wood decking, composite decking should overhang the edge of the deck. The decking overhang creates consistency in the overall deck appearances and hides many inconsistencies between the decking and deck’s substructure.

How far can 2x6 deck boards overhang?

So, for example, a 2×6 deck board could easily extend 11/2 inches beyond the edge of the supporting joist.

How much overhang can you have on decking?

As a general rule of thumb, it should not exceed 1/3rd of the boards’ width. For decking boards, it ranges from 1/4″ to 1 3/4″ inch. If you plan to picture frame your decking, many recommend an inch of overhang.

How much Trex expand and contract?

For Trex decking, the recommended end-to-end and side gaps range from 1/8 inch to 3/16 inch, depending on the temperature during installation. The gap against the permanent structure ranges from 1/4 inch to 1/2 inch, depending on the installation temperature.

Should a deck have an overhang?

When installing decking boards, be sure to allow for enough overhang to cover the fascia board and whatever additional amount you prefer. … This means the installed deck boards should have at least 1.75 to 2.75” overhang before the fascia is installed.

Can you overhang Trex decking?

» ALWAYS follow Trex-recommended gapping guidelines. » Maximum allowable perpendicular overhang for Trex is 102 mm. » All decks require air circulation to keep them dry and looking good. To improve air flow, leave openings under the decking or increase gapping to 10 mm.

Should I leave a gap between deck boards?

Proper wood deck board spacing should have at least a 1/8 inch gap after the decking has dried out. If you install your wood or treated deck boards while they are still wet boards, then they should be attached without a gap between them.

What is a deck overhang?

If the deck joists extend past the beam, they create a cantilever — an overhanging section of deck.

How far apart do you space Trex decking?

One of the most critical steps for properly securing composite decking in place is to make sure you have a 1/4-inch to 3/16-inch gap between the decking boards (don’t exceed 1/2 inch). This space is important for two reasons.

Article first time published on

Can you rip Trex decking?

Can you rip a Trex board? Trex products should not be ripped to reduce thickness, but can be ripped to reduce width. As long as the board can still be installed per the installation instructions, the warranty will be valid. Please use care when fastening ripped boards, as pre-drilling may be necessary.

Should you stagger Trex decking?

Composite decking should not be staggered on a deck. Staggered decking requires butt joints, but composite decking expands and contracts with temperature changes making butt joints unsightly.

What is an alternative to Trex?

• 01 of 08. Trex. Trex. …
• 02 of 08. TimberTech (AZEK) AZEK. …
• 03 of 08. Cali-Bamboo. Cali-Bamboo. …
• 04 of 08. Dura-Life. DuraLife. …
• 05 of 08. Envision Composite Lumber. Envision. …
• 06 of 08. Fiberon. Fiberon. …
• 07 of 08. CertainTeed EverNew. CertainTeed. …
• 08 of 08. Lumberock. Lumberock.

Does Trex make end caps?

Trex® Rail End Cap Cover.

How far can a deck board overhang a joist?

The American Wood Council states that cantilevers are limited to 1/4 the span of the joists. Joist Spacing (o.c.) Maximum allowable overhang cannot exceed 1/4 of the actual main span.

How much should a step overhang?

Stairs must have an overhang between 3/4″ to 1-1/4” to increase the depth of the step, making it better for descent while maintaining a clear 10-inch going for the ascent. Treads that are 11-inches deep or greater do not require an overhang.

How do you hide the edges of a composite deck?

The question is, how do you hide the ends of composite decking? There are several ways to go about it. Some of your options include picture framing, installing fascia boards, coating the ends with paint, using end caps and plugs, or edging your ground-level deck with stone.

How far can a cantilever extend?

According to the new span tables and IRC provisions, cantilevers can extend up to one-fourth the backspan of the joist. This means that joists, such as southern pine 2x10s at 16 inches on-center, spanning 12 feet are allowed to cantilever up to an additional 3 feet (see illustration, below).

How much cantilever is possible?

The deflection limit for cantilever beams set by most design codes is L/180 for live load and L/90 for combined dead & live load. The maximum span depends on the material of the beam (wood, steel or concrete).

How far can beam overhang post?

The American Wood Council’s Wood Frame Construction Manual states that beams can generally cantilever up to 1/4 their span over a post.

Why is my deck buckling?

Just like warping, bowing occurs when moisture leaves the boards causing the wood to shrink. By adding moisture back into the wood, you can correct the warping with a little bit of pressure.

Does composite decking expand when wet?

Do Composites Expand and Contract? Yes, composite decking materials do expand and contract in all directions, but not as much as real wood. Composites are resistant to moisture. Instead, they change in size due to temperature.

Can you put deck boards tight together?

Rot – Deck boards that are spaced too tightly together are more likely to trap dirt, debris and moisture, which is the perfect mixture for making rot. Water Drainage – Adequate gaps are needed for water drainage. Without it rot is more likely, mold can build up easily and slick boards can become hazardous.

How do you hide the ends of Trex decking?

Composite decking ends can be finished by picture framing, raised fascia board, painting the ends, attaching decking veneer, composite nosing strips, vinyl stair nosing cove, composite corner trim or plastic end caps.

Can Trex be installed on 16 inch centers?

Most composite and PVC decking brands, like Trex and Azek, recommend a maximum joist spacing of 16 inches OC. Some brands, like WearDeck, let you get away with more – reinforced with a layer of fiberglass on both the top and bottom, WearDeck boards easily allow for spans of 24 inches OC.

How many Trex boards do I need for a 12x12 deck?

Board lengthBoards required8 FT20612 FT13716 FT10320 FT83

Can you attach a deck to a cantilever?

Chuck Lockhart A deck ledger cannot be attached to cantilevered house framing. … Install a beam with posts and footings along the house end of the deck, just as you would at the outside of the deck. The beam can be built into the floor system—say a double or triple rim joist—or it can be placed beneath the deck joists.

How do you calculate cantilever on a deck?

Calculating cantilevers To determine the maximum allowable cantilever for a backspan (the span from the beam to the ledger), you need to do two checks. First, find the maximum cantilever on the table; second, divide the backspan by four. The lower number is the maximum cantilever you can use.

How far should posts be on a deck?

Layout and Footing Locations In general, posts should be spaced no more than 8 feet apart. Some builders position them every 4 feet for a completely rigid frame. The maximum distance between footings is determined by the size of your joist material.

Is Trex decking slippery when wet?

Trex decking is a low-maintenance decking solution that requires a fraction of the work of wood decks and is less likely to get slippery when wet. It still requires occasional attention to keep it looking its best, but you’ll be delighted with the finished results.

Does Trex sag?

Your composite deck may not warp, but it can sag and buckle. Most sagging is caused by improper spacing between the joists when it is installed. Also, thermal expansion, the fluctuation of temperatures, can have a more significant effect on composite decking than on natural wood decking.
