The reciprocating stepped-cone chisel head action of the Grundomat piercing tool is unique because it hammers away at solid obstacles. This two-stroke action means that the piston’s impact is concentrated on the reciprocating tool head for optimum trenchless boring performance.

What is grundomat?

The Grundomat method is an air driven piling system, which uses compressed air to drive the piles. The compressed air can be supplied from outside the piling area, using very small machinery and generates minimal vibration making it a useful technique for restricted access sites and in underground environments.

What is a grundomat mole?

Grundomat Mole Soil displacement moles for installing underground services, able to bore up to 50m. The unique reciprocating action stepped-cone chisel head allows displacement of any obstructions. Available from 45mm up to 180mm diameter.

How does a boring tool work?

boring machine, device for producing smooth and accurate holes in a workpiece by enlarging existing holes with a bore, which may bear a single cutting tip of steel, cemented carbide, or diamond or may be a small grinding wheel.

How do you reverse a grundomat?

The GRUNDOMAT can be reversed if it encounters an unfracturable obstacle or if it is used for making dead-end holes. When reversing, the operator should firmly hold the hose and make sure that the tool does not back over it.

What is the process of boring?

In machining, boring is the process of enlarging a hole that has already been drilled (or cast) by means of a single-point cutting tool (or of a boring head containing several such tools), such as in boring a gun barrel or an engine cylinder. … There are various types of boring.

How far can you horizontal bore?

Maximum lengths and hole diameters are determined by project specific geotechnical conditions however effective outside range for heavy rig horizontal directional drilling is 3,000 m (9,843′). Light rigs are typically used for crossings between 50 m and 1,000 m (164′ – 3,281′).

How does impact moling work?

Impact moling is an unguided soil displacement technique in which a percussive mole is launched from a small excavation to form a bore through the ground. The new conduit is normally drawn in behind the mole or pulled back into the bore using the hammers reverse action.

Can you directional bore through rock?

In the past, the presence of rock formations prevented the use of horizontal directional drilling (HDD) for most underground utility construction. … As technology has advanced, midsize drilling equipment now has the capability of effectively drilling and steering in rock.

How does a pneumatic mole work?

It works as a pneumatic cylinder with pulsed compressed air causing the head of the mole to repeatedly hammer against the soil in front of the mole. Once the mole has passed through the earth the pipe can be pulled through the long horizontal hole.
